MASTER DELAY This page allows the programming of delay lines for the channels A and B as well as
for the summed input A+B.
CHANNEL EQ The CHANNEL EQ page offers access to the 4-band parametric equalizers of the
sound system processor outputs for speaker equalization.
X-OVER Frequency crossover-filters as well as the parameters gain, polarity and alignment-
delay for all output channels are located in the X-OVER area.
DYNAMICS This page provides access to compressor and limiter of each channel.
The FLOW DIAGRAM window shows a signal flow diagram, which offers a quick overview of all DSP setting of the
sound system processor. Labeling and routing channels, editing trim and mute can be done directly in the diagram.
Clicking onto the corresponding function blocks lets you access all other DSP parameters. All parameters that are
necessary for using presets, configurations and RACE files are also accessible from this window.
The FLOW DIAGRAM window opens when clicking on the first, fourth or eight block in the Flow Diagram Selector.
IRIS-Net
DIGITAL SOUND PROCESSOR | en 554
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
