First, you have to select the desired CrossMax file by use of the Browse... button. Because a CrossMax file can hold the
data of up to 31 DSP 244, you need to continue by selecting the desired device from the CrossMax file within the
dialog ”SELECT DEVICE FROM CrossMax FILE”. Clicking onto ”OK” button completes the process.
Caution!
The loaded preset becomes instantly audible when in on-line mode. Be sure to select the desired
preset with the correct set of parameters. In the worst case, this could lead to severe damage to
the connected loudspeaker cabinets due to improper signal processing!
Consequences
MASTER EQ
Both input channels of the sound system processor employ 5-band parametric equalizers each, which allow
programming highly variable full-range speaker equalization to match a PA-system to different environmental and
acoustical requirements. In many cases post-mixing console parametric equalization becomes redundant. The Master-
EQ is selected by clicking on the second block of the flow diagram selector or on the MASTER EQ block in the full-scale
flow diagram.
IRIS-Net DIGITAL SOUND PROCESSOR | en 587
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
