Limiter Parameters
Element Default Range Description
Default (39
dB)
Default (39 dB), S900, S1200,
CL800, CL1200, CL1600,
CL2000, LX1600, LX2200,
LX3000, L1000 (0dBu), L1000
(+6dBu), L1000 (26dB), L1600
(0dBu), L1600 (+6dBu), L1600
(26dB), L2400 (0dBu), L2400
(+6dBu), L2400 (26dB), H
2500 (0dBu), H 2500 (32dB), H
2500
(35 dB), H 5000 (0dBu), H
5000 (32dB), H 5000 (35dB),
SL900, SL1200, SL1800,
SL2400, DSA8204, DSA8206,
DSA8209, DSA8212
Select the amplifier type connected to output of the
DSP 600.
123 Vpk AMP THRESH determines the audio signal level
above which the peak limiter starts operating.
2 dBu DSP THRESH determines the audio signal level
above which the peak limiter starts operating. This
value may change depending on the AMP- LIFIER
type that is selected, as the sensitivity and output
power are automatically calculated with the Vpk
value to provide DSP Threshold.
User User, Hi, Mid, Lo, Sub TYPE allows a user to select a bandpass type, and
the software will enter appropriate default time
constants for the bandpass selected. DYNACORD
speaker settings include factory-defined time
constants, so this section is only for use when
creating DSP settings from scratch.
0 ms 0 to 50 ms ATTACK determines how fast the limiter reduces
amplification when the threshold is exceeded.
100 ms 10 bis 1000 ms RELEASE determines how fast the limiter returns to
normal amplification, after the audio signal level
declined the threshold.
Press the ACTIVE button to deactivate the peak
limiter.
The ACTIVATED LED lights green if the TEMP limiter
is active.
