ARRAY DELAY Block:
This displays the Array Delay of the output channels. The delay-value is displayed together with the
measurement unit. The graph shows the approximate usage of delay memory capacity. A single click
with the left mouse button onto this block opens the Array Delay page.
Clicking with the right mouse button opens the Copy & Paste menu, which allows copying all
parameters of the corresponding Delay block to any other ARRAY DELAY block within the same
project.
SPEAKER PROCESSING PEQ Block:
The SPEAKER PROCESSING PEQ block displays the 6 Channel EQs of the corresponding output
channel. The 6 LEDs indicate which EQ-bands are being used while the graph shows the frequency
response of the PEQ block. A single click with the left mouse button onto this block opens the
Output Parametric EQ page.
Clicking with the right mouse button opens the Copy & Paste menu, which allows copying all
parameters of the corresponding Speaker EQ block to any other EQ block within the same project.
SPEAKER PROCESSING X-OVER Block:
This block represents the crossover within the corresponding output channel. The graph shows the
frequency response that results from the set X-Over parameters. Three additional LEDs indicate the
status of gain trim (TRIM), polarity (INV) and delay (DLY). A single click with the left mouse button
onto this block opens the Output X-Over page. Clicking with the right mouse button opens the Copy
& Paste menu, which allows copying all parameters of the corresponding X-Over block to any other
Dx46 X-Over block within the same project.
SPEAKER PROCESSING FIR FILTER Block:
This block represents the FIR Filter within the corresponding output channel. The graph shows the
frequency response that results from the set FIR parameters. The LED indicate if the FIR Filter is
being used. A single click with the left mouse button onto this block opens the Output FIR page.
Clicking with the right mouse button opens the Copy & Paste menu, which allows copying all
parameters of the corresponding FIR Filter block to any other FIR Filter block within the same
project.
SPEAKER PROCESSING DELAY Block:
This displays the SPEAKER PROCESSING DELAY of the output channels. The delay-value is displayed
together with the measurement unit. The graph shows the approximate usage of delay memory
capacity. A single click with the left mouse button onto this block opens the Speaker Processing
Delay page.
Clicking with the right mouse button opens the Copy & Paste menu, which allows copying all
parameters of the corresponding Delay block to any other Dx46 Speaker Delay block within the
same project.
IRIS-Net DIGITAL SOUND PROCESSOR | en 660
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
