Allows selection of the FIR filter type of the corresponding
output channel.
Press this button to generate the FIR filter.
OUTPUT DELAY
Individual output delays can be set for each output channel of the Dx46.
HINT: The Dx46’s output delays can be used to compensate for the positioning of cabinets or speaker arrays
relative to each other or the original sound source, for example aligning the PA to the stage or aligning the full-
range loudspeakers to the subwoofers. The Output Delay parameter determines the delay time of the
corresponding channel or the distance between different loudspeaker clusters.
You can select the output delay window by clicking onto the eleventh block (DLY) in the Flow Diagram Selector or on
the SPEAKER PROCESSING DELAY block in the flow diagram.
IRIS-Net DIGITAL SOUND PROCESSOR | en 685
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
