/IDX35 speaker peq 2 gain -18 to +12 dB
/IDX36 speaker peq 2 quality 0.4 to 40
/IDX37 speaker peq 3 bypass 0 / 1 0 = active, 1 = bypass
/IDX38 speaker peq 3 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX39 speaker peq 3 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX3A speaker peq 3 frequency 20 to 20000 Hz
/IDX3B speaker peq 3 gain -18 to +12 dB
/IDX3C speaker peq 3 quality 0.4 to 40
/IDX3D speaker peq 4 bypass 0 / 1 0 = active, 1 = bypass
/IDX3E speaker peq 4 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX3F speaker peq 4 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX40 speaker peq 4 frequency 20 to 20000 Hz
/IDX41 speaker peq 4 gain -18 to +12 dB
/IDX42 speaker peq 4 quality 0.4 to 40
/IDX43 speaker peq 5 bypass 0 / 1 0 = active, 1 = bypass
/IDX44 speaker peq 5 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX45 speaker peq 5 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX46 speaker peq 5 frequency 20 to 20000 Hz
/IDX47 speaker peq 5 gain -18 to +12 dB
/IDX48 speaker peq 5 quality 0.4 to 40
/IDX49 speaker peq 6 bypass 0 / 1 0 = active, 1 = bypass
/IDX4A speaker peq 6 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX4B speaker peq 6 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX4C speaker peq 6 frequency 20 to 20000 Hz
/IDX4D speaker peq 6 gain -18 to +12 dB
/IDX4E speaker peq 6 quality 0.4 to 40
/IDX4F hipass xover type 0 to 17 0 = off, 1 = butter6, 2 = s12q05, 3 = s12q06, 4 = s12q07, 5
= s12q08, 6 =
s12q10, 7 = s12q12, 8 = s12q15, 9 = s12q20, 10 =
bessel12, 11 = butter12, 12
= linkwz12, 13 = bessel18, 14 = butter18, 15 = bessel24, 16
= butter24, 17 = linkwz24
IRIS-Net DIGITAL SOUND PROCESSOR | en 706
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
