/IDX17 array peq 2 gain -18 to +12 dB
/IDX18 array peq 2 quality 0.4 to 40
/IDX19 array peq 3 bypass 0 / 1 0 = active, 1 = bypass
/IDX1A array peq 3 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX1B array peq 3 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX1C array peq 3 frequency 20 to 20000 Hz
/IDX1D array peq 3 gain -18 to +12 dB
/IDX1E array peq 3 quality 0.4 to 40
/IDX1F array peq 4 bypass 0 / 1 0 = active, 1 = bypass
/IDX20 array peq 4 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX21 array peq 4 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX22 array peq 4 frequency 20 to 20000 Hz
/IDX23 array peq 4 gain -18 to +12 dB
/IDX24 array peq 4 quality 0.4 to 40
/IDX25 array peq 5 bypass 0 / 1 0 = active, 1 = bypass
/IDX26 array peq 5 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX27 array peq 5 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX28 array peq 5 frequency 20 to 20000 Hz
/IDX29 array peq 5 gain -18 to +12 dB
/IDX2A array peq 5 quality 0.4 to 40
/IDX2B speaker peq 1 bypass 0 / 1 0 = active, 1 = bypass
/IDX2C speaker peq 1 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX2D speaker peq 1 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX2E speaker peq 1 frequency 20 to 20000 Hz
/IDX2F speaker peq 1 gain -18 to +12 dB
/IDX30 speaker peq 1 quality 0.4 to 40
/IDX31 speaker peq 2 bypass 0 / 1 0 = active, 1 = bypass
/IDX32 speaker peq 2 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX33 speaker peq 2 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX34 speaker peq 2 frequency 20 to 20000 Hz
IRIS-Net DIGITAL SOUND PROCESSOR | en 705
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
