/IDX85 input channel name max. 30
characters
/IDX86 audio input gain -60 to +12 audio input gain in dB
Output channel 1 to 6
Index Parameter Values Description
/IDX00 lock flag list for output
parameters
NONE, 0 to 61 „Set“ means locked
/IDX01 hide flag list for output
parameters
NONE, 0 to 61 „Set“ means hidden
/IDX02 connected amp model ASCII chars Default, User or Dynacord/ EV amp types
/IDX03 gain of amp model „User“ 0 to 60 dB
/IDX04 Pilot generator enable 0 / 1 0 = off, 1 = on
/IDX05 Pilot generator level -128 to 0 dB
/IDX06 route A, A+B, B selects the input signal
/IDX07 array delay bypass 0 / 1 0 = active, 1 = bypass
/IDX08 array delay 0 to 100 default milliseconds, units can be appended (ms, samples,
feet, inch, meter, cm, us, sec)
/IDX09 xover delay bypass 0 / 1 0 = active, 1 = bypass
/IDX0A xover delay 0 to 20 default milliseconds, units can be appended (ms, samples,
feet, inch, meter, cm, us, sec)
/IDX0B output delay bypass 0 / 1 0 = active, 1 = bypass
/IDX0C output delay 0 to 1000 default milliseconds, units can be appended (ms, samples,
feet, inch, meter, cm, us, sec)
/IDX0D array peq 1 bypass 0 / 1 0 = active, 1 = bypass
/IDX0E array peq 1 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX0F array peq 1 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX10 array peq 1 frequency 20 to 20000 Hz
/IDX11 array peq 1 gain -18 to +12 dB
/IDX12 array peq 1 quality 0.4 to 40
/IDX13 array peq 2 bypass 0 / 1 0 = active, 1 = bypass
/IDX14 array peq 2 type 0 to 5 0 = peq, 1 = loshelv, 2 = hishelv, 3 = locut, 4 = hicut, 5 =
allpass
/IDX15 array peq 2 slope 1 / 2 1 = 6dB, 2 = 12dB
/IDX16 array peq 2 frequency 20 to 20000 Hz
IRIS-Net DIGITAL SOUND PROCESSOR | en 704
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
