OPEN INTERFACE Select the checkboxes of the error types to be available via the ASCII Control
Protocol of the DPM.
If DPC 8015 call stations are configured for error indication, the text entered here
is indicated in the call station display if the error occurs. The maximum number of
characters is 11 when using system languages Korean or Chinese. The maximum
number of characters is 20 when using other system languages.
HINT: The meaning of the parameter %u is described at the error types below.
MEMORY/DATA Memory or Read/Write error.
WATCHDOG Watchdog error of the DPM. This error type is logged conforming to standards,
press the CLEAR button to reset the error.
FIRMWARE The DPM firmware version is not compatible with the IRIS-Net version used. A
firmware update is recommended.
MODULES Invalid module configuration of the DPM 8016. The parameter %u gives the slot
number of the invalid module.
HARDWARE Error in the power supply or the A/D converters of the DPM 8016.
TEMPERATURE Temperature overload of the DPM 8016.
TEMP Current temperature on the inside of the enclosure.
AUDIO
PROCESSING
Error during the processing of audio data.
INPUT PILOT
DETECTION
Pilot tone detection fault at the inputs of the DPM 8016. The parameter %u gives
the number of the input. The inputs of the UI-1 modules are numbered ascending.
Example:
The parameter %u has the value 6 if there is a detection fault at the IN B/C input
of the UI-1 module in slot 8.
PMX-MM-2
MODULE
Error in the PMX-MM-2 module. Please refer to page 525 for details.
IRIS-Net PROMATRIX 8000 | en 728
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
