Supervision Dialog
The Supervision window shows the condition of the DPM 8016. When on-line, all fault conditions are being indicated. It
is possible to select for each type of error whether it is displayed in a collected fault message, buffered and/or
indicated at the call station displays.
Element Description
The current condition of each type of error gets indicated. Green means no error,
red indicates that an error has been detected.
At the occurrence of a type of error for which the checkbox DETECT is ticked, the
COLLECTED ERROR STATE flag is set at the same time. Additionally the FAULT-
LED on the front panel of the DPM lights, the FAULT relay opens and a signal
sound.
Detected types of errors for which the checkbox HOLD is ticked are stored.
Sporadic errors are indicated until the corresponding HOLD checkbox is
unchecked.
IRIS-Net PROMATRIX 8000 | en 727
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
