DPC DEVICE A connected DPC call station has transferred an error message. The parameter
%u gives the address of the erroneous call station.
DPA DEVICES A connected DPA power amplifier has transferred an error message. The
parameter %u gives the address of the erroneous amplifier.
DCS DEVICES A connected DCS system has transferred an error message. The parameter %u
gives the address of the erroneous DCS system.
PWS DEVICES A connected PWS wall station has transferred an error message. The parameter
%u gives the address of the erroneous wall station.
POWER SUPPLY Fault condition in the power supply of the DPM 8016.
SPEAKER LINE
FAULT
Fault condition in the speaker line supervision.
The parameter %u gives the number of the erroneous speaker line, the number
has following meaning:
1 to 500: Zone A
501 to 1000: Zone B
USER FAULT 1 to
10
One or more USER FAULTS have been set
HINT: Use the DPM Task Engine to configure USER FAULTS.
COLLECTED
ERROR
The FAULT-LED on the front panel of the DPM 8016 lights at the occurrence of
this type of error.
Manually setting or resetting an error.
DSP Dialog
In this dialog the DSP configuration of the DPM 8016 is shown. Double clicking on a DSP-Block’s icon allows editing its
configuration and settings in detail.
IRIS-Net PROMATRIX 8000 | en 730
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
