Off Select the LED of the button that should indicate the value „0“ of the logic variable:
– Primary LED (green/red)
– Secondary LED (yellow)
– None
Parameter The logic variable whose value is being changed. This can be the keyword Pagings.VControl1.Value
which can be used to start a signal. See Pagings Dialog, page 762 on how to configure the conditions
for a logical key.
Active when
locked
Selecting this checkbox allows the user to press the button even though the call station has been
locked.
Arithmetical Key
A switch of the type "Arithmetical Key" allows changing the value of a numerical variable. Pressing the button on the
call station either increases or decreases the value of the numerical variable.
Element
Description
Mode Select the desired parameter change that is to be executed when pressing the button on the call station:
– Up = increases the value of the numerical variable
– Down = decreases the value of the numerical variable
Parameter The numerical variable whose value is being changed.
Min The lower limit of the value range. Using the "Down" mode decreases the value of the numerical variable
till down to this value.
Max The upper limit of the value range. Using the "Up" mode increases the value of the numerical variable till
up to this value.
Step Size Lets the user enter the step width by which the value is to be changed when pressing the button on the
call station.
Repeat
Time
Lets the user enter a value for the time interval in milliseconds after which (when keeping the button
pressed) the numerical value is being changed by the set step width art any one time. Entering "0"
changes the value only once, even when keeping the button pressed over a longer period of time.
Active
when
locked
Selecting this checkbox allows the user to press the button even though the call station has been locked.
IRIS-Net PROMATRIX 8000 | en 802
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
