Element Description
The current condition of each type of error gets indicated. Green means no error, red
indicates that an error has been detected.
At the occurrence of a type of error for which the checkbox DETECT is ticked, the
COLLECTED ERROR STATE flag is set at the same time and the FAULT-LED at the DPC
lights.
DEVICE CONNECTED The PCA bus connection between DPM and DPC is broken.
SLOT POSITION The call station is not connected to the correct slot position.
MEMORY Memory error in DPC.
WATCHDOG + CLEAR Watchdog error in DPC. This error type is logged according standards, press the
CLEAR button to reset the error.
FIRMWARE The firmware version of the DPC is to old.
IRIS-Net PROMATRIX 8000 | en 808
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
