Interface From this window the interfaces (e.g. CAN bus, GPIO control port) can all be configured.
HINT: Ethernet interface settings are edited under General dialog in the paragraph Network
Settings.
Power Management From this window the power management of the device can be configured.
LineSupervision The line supervision of the device can be controlled and supervised from this window.
Topology/Zones This windows lets you configure topologies and zones of the system.
General Dialog
Double clicking on a PMX-4CR12 by default opens the General dialog box. Here, the user can make basic settings that
are necessary for flawless operation. All elements of the displayed PMX-4CR12 front panel are active in on-line mode
and correspond to the actual indicators on the unit.
Notice!
System language Korean or Chinese
For using system languages Korean or Chinese the call station firmware type “CST_Vx.x.xA” has to
be used. Please be patient when uploading this firmware to the call station.
IRIS-Net PROMATRIX 6000 | en 836
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
