Element Description
IP ADDRESS Indicates the IP address of the PMX-4CR12’s Ethernet port (factory setting:
192.168.1.100). Enter the address of the PMX-4CR12 with which you want to
establish on-line communication.
NETWORK MASK Indicates the Ethernet port’s network mask (factory setting: 255.255.255.0).
GATEWAY ADDRESS Indicates the standard gateway of the Ethernet port (factory setting:
192.168.1.1).
MAC ADDRESS Indicates the MAC address of the connected PMX-4CR12 when on-line. The
MAC address of the PMX-4CR12 is also shown on a label on the unit’s rear
panel.
NAME IRIS-Net internal device name of the PMX-4CR12.
BUZZER Select ON to indicate a connection failure to a call station (selectable via the
drop down field) via the integrated buzzer of the PMX-4CR12.
SYSTEM LANGUAGE Select the system language of the PROMATRIX 6000 system. Please note to
update the call station firmware when selecting Korean or Chinese.
VOICE ALARM STATE This indicator shows “ACTIVE” if the device is in voice alarm state, else “NOT
ACTIVE”.
RESET Press the RESET button to deactivate the voice alarm state.
PRIORITY Select the priority (70–100) of the voice alarm. Select OFF to disable the
voice alarm handling of the device.
AUTO EXIT Select this checkbox if the voice alarm state should be stopped automatically
after the alarm signal is stopped/muted (e.g. no alarm request present). This
checkbox is disabled if the voice alarm priority is set to OFF.
VOICE ALARM RECORDING Select this checkbox if the signals above voice alarm priority should be
recorded automatically. By default it is unchecked and is enabled only in
offline mode. It is disabled if the voice alarm priority is OFF.
VOICE ALARM ANNOUNCEMENTS Select this radio button if only announcements (live signals from a CST or
emergency microphone) above voice alarm priority should be recorded. This
control is enabled only in the offline mode, when VOICE ALARM RECORDING
is checked and It is selected by default. It is disabled if the voice alarm
priority is OFF.
ALL VOICE ALARM SIGNALS Select this radio button if all signals above voice alarm priority should be
recorded. This control is enabled only in the offline mode, when VOICE
ALARM RECORDING is checked. It is disabled if the voice alarm priority is
OFF.
DATE/TIME Date and time of the PMX-4CR12 system clock.
INTERNAL CLOCK
Opens the system clock settings dialog box.
DCF77 SYNCHRONIZATION Select this option to synchronize the internal clock of the PMX-4CR12 with
the DCF77 signal. Please refer to the manual how to connect an external
DCF77 receiver.
IRIS-Net PROMATRIX 6000 | en 837
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
