Supervision Dialog
The Supervision window shows the condition of the PMX-4CR12. When on-line, all fault conditions are being indicated.
It is possible to select for each type of error whether it is displayed in a collected fault message, buffered and/or
indicated at the call station displays.
Element Description
STATE The current condition of each type of error gets indicated. Green means no error,
red indicates that an error has been detected.
NOTIFICATON At the occurrence of a type of error for which the checkbox DETECT is ticked, the
COLLECTED ERROR STATE flag is set at the same time. Additionally the FAULT-
LED on the front panel of the device lights, the FAULT relay opens and a signal
sound.
HOLD Detected types of errors for which the checkbox HOLD is ticked are stored.
Sporadic errors are indicated until the corresponding HOLD checkbox is
unchecked.
LOG
IRIS-Net PROMATRIX 6000 | en 839
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
