NUMBER OF ANALOG VALUES Enter the number of analog values of the task engine to be available via the ASCII
control protocol.
IS ALIVE PERIOD (s) Enter the is alive period of the ASCII control protocol in seconds.
PASSWORD If password protection of the ASCII control protocol is required, enter the
password here. Repeat the password in the CONFIRM PASSWORD field. Go
online (write) to set the password in the device.
HINT: Editing the password setting is possible in offline mode only.
DPM 4000 INTERFACE
ENABLE Set the checkbox to activate the RS-232 interface between a DPM 4000 and the
PMX-4CR12. Available only for the PMXCON_1.
AUDIO OUTPUT Indicates the audio output of the PMX-4CR12, that outputs the audio signal to the
DPM 4000.
AUDIO INPUT Select the audio input number of the DPM 4000.
MEMOFLAG BROKEN LINE The DPM 4000 memo flag selected here is used for supervising the RS-232
connection.
CONTROL IN
STATE Displays the control inputs’ current state.
VOLTAGE Displays the control inputs’ current voltage.
FAULT MON Set the checkbox of supervised control inputs to activate the supervision.
ACTIVE Set the upper and lower bound (voltage) of the ACTIVE state of the supervised
control inputs.
OK Set the upper and lower bound (voltage) of the OK state of the supervised
control inputs.
CONTROL OUT
STATE It is possible to manually change the condition of the control outputs (normally
open contact / normally closed contact).
PowerManagement Dialog
The Power Management dialog allows configuring the standby mode of the device in detail.
IRIS-Net PROMATRIX 6000 | en 872
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
