Element Description
IP ADDRESS Indicates the IP address of the PVA-4CR12’s Ethernet port (factory setting:
192.168.1.100). Enter the address of the PVA-4CR12 with which you want to
establish on-line communication.
NETWORK MASK Indicates the Ethernet port’s network mask (factory setting: 255.255.255.0).
GATEWAY ADDRESS Indicates the standard gateway of the Ethernet port (factory setting:
192.168.1.1).
MAC ADDRESS Indicates the MAC address of the connected PVA-4CR12 when on-line. The
MAC address of the PVA-4CR12 is also shown on a label on the unit’s rear
panel.
NAME IRIS-Net internal device name of the PVA-4CR12.
BUZZER Select ON to indicate a connection failure to a call station (selectable via the
drop down field) via the integrated buzzer of the PVA-4CR12.
SYSTEM LANGUAGE Select the system language of the PAVIRO system. Please note to update the
call station firmware when selecting Korean or Chinese.
VOICE ALARM STATE This indicator shows “ACTIVE” if the device is in voice alarm state, else “NOT
ACTIVE”.
RESET Press the RESET button to deactivate the voice alarm state.
PRIORITY Select the priority (70–100) of the voice alarm. Select OFF to disable the
voice alarm handling of the device.
AUTO EXIT Select this checkbox if the voice alarm state should be stopped automatically
after the alarm signal is stopped/muted (e.g. no alarm request present).
DATE/TIME Date and time of the PVA-4CR12 system clock.
INTERNAL CLOCK
Opens the system clock settings dialog box.
DCF77 SYNCHRONIZATION Select this option to synchronize the internal clock of the PVA-4CR12 with
the DCF77 signal. Please refer to the manual how to connect an external
DCF77 receiver.
DCF77 SIGNAL STATUS Indicates the DCF77 signal strength:
– Green: Signal strength OK
– Red: Signal strength not OK
NETWORK SYNCHRONIZATION Select this option to synchronize the internal clock of this PVA-4CR12 with
the internal clock of another PVA-4CR12 connected via Ethernet.
TIME MASTER Select the PVA-4CR12 (connected via Ethernet) to synchronize the internal
clock with. This drop down can only be used if the NETWORK
SYNCHRONIZATION option is selected.
ENABLE SLAVE CLOCK Select this checkbox if slave clocks are connected to the PVA-4CR12.
CURRENT SLAVE CLOCK TIME Set the time for the slave clocks.
FIRMWARE Indicates the firmware version of the PVA-4CR12 when on-line.
IRIS-Net PAVIRO | en 914
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
