TaskEngine Dialog
The Task Engine Window allows configuring the Task Engine by dragging inputs, links or outputs from the categories of
the FUNCTIONS AND IOS on the left corner of the screen into the Task Engine Worksheet. Elements can be freely
positioned and wired within the worksheet. Double clicking on inputs or outputs allows configuring them in detail.
Copy & paste of blocks allow convenient editing of the Task Engine configurations. The size of the worksheet
automatically increases when a block is moved to the current border.
Configuring the Task Engine as well as wiring DSP blocks is possible only in offline mode. Please refer to section “How
to configure a Control” on page 20 how to assign functions and connections to a Task Engine block.
Notice!
The Task Engine structure calculation is only executed after state changes, so it can occur that a
state of one block differs from the state of the next block, for example, when an audio block
(alarm, announcement, message, etcetera) is overwritten by a conflicting existing paging with
higher priority.
VALUES
Element Description
The Input Analog block is a variable parameter for rational numbers which
always outputs the current value of the connection.
The Output Analog block is a variable parameter for rational numbers which
always assigns the current value at the input to the connection.
IRIS-Net PAVIRO | en 927
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
