NUMBER OF ANALOG VALUES Enter the number of analog values of the task engine to be available via the ASCII
control protocol.
IS ALIVE PERIOD (s) Enter the “is alive period” of the ASCII control protocol in seconds.
PASSWORD If password protection of the ASCII control protocol is required, enter the
password here. Repeat the password in the CONFIRM PASSWORD field. Go
online (write) to set the password in the device.
HINT: Editing the password setting is possible in offline mode only.
FPA 5000 INTERFACE
ENABLE Set the checkbox to activate the connection between a FPA 5000 and the
PVA-4CR12 via Ethernet. Available only for PVACON_1
TCP Port TCP port of the FPA 5000 interface. The default port is 9401.
USERNAME Enter the username defined in the FPA.
PASSWORD Enter the password defined in the FPA.
CONTROL IN
STATE Displays the control inputs’ current state.
VOLTAGE Displays the control inputs’ current voltage.
FAULT MON Set the checkbox of supervised control inputs to activate the supervision.
ACTIVE Set the upper and lower bound (voltage) of the ACTIVE state of the supervised
control inputs.
OK Set the upper and lower bound (voltage) of the OK state of the supervised
control inputs.
CONTROL OUT
STATE It is possible to manually change the condition of the control outputs (normally
open contact / normally closed contact).
PowerManagement Dialog
The Power Management dialog allows configuring the standby mode of the device in detail.
IRIS-Net PAVIRO | en 949
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
