STATE The port state; can be one the following:
– Disabled
– Discarding
– Learning
– Forwarding
PATH COST The contribution of this port to the root path cost.
ROLE The port role; can be one of the following:
– Disabled
– Alternate
– Backup
– Root
– Designated
– Master
LAST CHANGE The number of seconds since the last change on this port.
ASCII Control Protocol
The Controller can be easily integrated into media or touch panel controls via the Ethernet interface. This section
describes how to connect via Ethernet and the available options of the control protocol.
ETHERNET CONNECTION
To connect an external device to the Controller via Ethernet, the Ethernet port of the Controller must be configured.
Following table lists the keywords of the Controller for Ethernet configuration.
Keyword Values Default Description
OpenIntActive 0, 1 0 This keyword allows activating or deactivating the ASCII
Control Protocol. If deactivated, a connection via Ethernet is
not possible.
– OpenIntActive = 1: The ASCII Control Protocol is activated
– OpenIntActive = 0: The ASCII Control Protocol is not
activated
OpenIntPort 6273 The Ethernet port for the TCP connection between the
Controller and the external device.
Following table lists the default setting of the Controller’s Ethernet port.
Parameter
Default
IP address 192.168.1.100
Network mask 255.255.255.0
Standard gateway 192.168.1.1
Port 6273
HINT: Only one single Ethernet connection can be used at one time.
IRIS-Net
PAVIRO | en 962
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
