HINT: The password protection of the ASCII Control Protocol can be configured at the Interfaces dialog of the
Controller.
ZONE STATUS
Whenever the output status of the local zones changes, a zone status string is sent via the ASCII Control Protocol. The
format of the zone status string is: <Idx.y> <Change> <Pm> <Zone Pattern>
Element Description
Idx.y Unique identifier:
x is the number x in the IRIS-Net internal device name, e.g. „Device_x“
y is a unique paging request number of the local Controller
Change ON, if the paging request Idx.y has activated one or more local audio outputs of the Controller
OFF, if the paging request was terminated and the corresponding local audio outputs of the
Controller have been deactivated
Pm Priority of the paging request
Zone Pattern List of activated local zones of the Controller.
Examples:
Id3.7 ON P12 Z2-3
Id3.7 OFF
WATCHDOG FUNCTION
If the ASCII Control Protocol is activated and also the watchdog string output is activated, following string is sent via
the ASCII Control Protocol at regular intervals: “Open IntIs Alive”
Keyword
Range Default Description
Open IntIs Alive
Period
0, 1,..., 100 0 This keyword is used to active or deactivate
the output of the watchdog string. When
activated the output time period can be
adjusted.
– Open IntIs Alive Period = 0: No output of
the watchdog string.
– Open IntIs Alive Period = 1...100: The
watchdog string is output every 1...100
seconds.
Example:
Open IntIs Alive Period = 15: The watchdog
string is output every 15 seconds.
INPUT VIA THE ASCII CONTROL PROTOCOL
The ASCII Control Protocol allows entering values for input parameters (rational numbers or Boolean values) of the
Controller’s Task Engine. The number of logic or analog values is set in the Interfaces dialog.
Logic values
Following format is used to edit the value of a logic value: <LVal><id> <value>
Element
Description
LVal Indicates the use of a logic value in the Task Engine
IRIS-Net PAVIRO | en 963
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
