OK Set the upper and lower bound (voltage) of the OK state of the supervised
control inputs.
CONTROL OUT
STATE It is possible to manually change the condition of the control outputs
(normally open contact / normally closed contact).
Supervision Dialog
The Supervision window shows the condition of the PVA-4CR12. When on-line, all fault conditions are being indicated.
It is possible to select for each type of error whether it is displayed in a collected fault message, buffered and/or
indicated at the call station displays.
Element Description
STATE The current condition of each type of error gets indicated. Green means no error,
red indicates that an error has been detected.
IRIS-Net PAVIRO | en 967
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
