10
Aesculap
®
Full HD CMOS Camera System
Calling up the menu
The camera has a menu that appears as text on the screen ("on-screen dis-
play" or OSD). The menu appears on the screen by pressing and holding
(> 1 s) button A 20 (up).
Navigation in the menu
By actuating buttons A 20 (up) and C 23 (down) it is possible to navigate
within the menu. As soon as a menu point is marked, this can be activated
by actuating button B 21 (right) and then modified by pressing
button B 21 (right) or button D 22 (left).
Overview of the main menu
Overview of the "profile" menu
Note
Once a profile has been chosen, the menu will close automatically and the
user will be back in the operation mode (live image).
Menu
Profile Preinstalled camera settings, optimized to
the use. The choices are:
Laparoscopy
Arthroscopy
Hysteroscopy
Neuro 1
Neuro 2
Fiberscope
Users 1, 2, 3 (programmable by the user)
Brightness Setting brightness manually
Saturation Setting color saturation manually
Digital zoom Setting digital zoom up to factor 2.5
Sharpness Setting edge enhancement manually
Contrast Setting contrast manually
System setup Opens a submenu with other settings
Save and exit Save setting and exit menu
Exit Changes will not be saved, exit menu
Profile
Laparoscopy Camera settings optimized for this use
Arthroscopy Camera settings optimized for this use
Hysteroscopy Camera settings optimized for this use
Neuro 1 Camera settings optimized for this use
Neuro 2 Camera settings optimized for this use
Fiberscope Camera settings optimized for this use
User 1 Camera settings saved by the user; disk
space 1
User 2 Camera settings saved by the user; disk
space 2
User 3 Camera settings saved by the user; disk
space 3
User settings Opens submenu. The "User 1/2/3" settings
can be defined there.
Return Returns the user to the main menu
