11
Overview of the "system setup" menu Overview of the "user settings" menu
System setup
Language Setting the menu language
Button layout Opens a submenu in which the camera
head buttons can be assigned
Image format Sets the image refresh rate
Selectable options: 50 Hz/60 Hz
Light source Switch the light source on or to standby
(only in conjunction with Aesculap LED
light source OP940)
Selectable options: On/standby
System information Opens a submenu with other settings
Return to default settings Restore all settings to the original values
Return Takes the user back to the previous menu
User settings
Ref. profile Here, a profile can be selected as a basis for
the other settings. The choices are:
Laparoscopy
Arthroscopy
Hysteroscopy
Neuro 1
Neuro 2
Fiberscope
Brightness Setting brightness manually
Saturation Setting color saturation manually
Digital zoom Setting digital zoom manually
Sharpness Setting edge enhancement manually
Contrast Setting contrast manually
Save as Here, disk space can be established for the
settings. The choices are:
User 1
User 2
User 3
Return and save Saves the settings and takes the user back
to the previous menu
Return Takes the user back to the previous menu
without saving the changes
