3-27
Confidential
8.6 INNER CHUTE ASSY
(1) Remove the two Taptite bind B M4x12 screws, and then remove the Inner chute ASSY
from the Main body.
Fig. 3-19
Taptite bind B M4x12
Inner chute ASSY
