3-26
Confidential
8.5 JOINT COVER SUB CHUTE ASSY
(1) Remove the two Taptite bind B M4x12 screws, and then remove the Joint cover sub
chute ASSY from the Main body.
Fig. 3-18
Taptite bind B M4x12
Joint cover sub chute ASSY
