3-96
Confidential
8.38 MAIN SHIELD PLATE / EJECT SENSOR PCB ASSY
(1) Remove the three Taptite bind B M3x10 screws, and then remove the FU front paper
guide from the Main body.
Fig. 3-100
Taptite bind B M3x10
FU front paper guide
