3-40
Confidential
8.11.7
LOWER DOCUMENT CHUTE ASSY
(1) Remove the two Taptite cup B M3x10 screws, and then remove the Lower document
chute ASSY from the Document cover sub ASSY.
Fig. 3-35
Lower document chute ASSY
Taptite cup B M3x10
Rib
Document cover sub ASSY
Rib
Taptite cup B M3x10
Rib
