3-39
Confidential
(3) Release the Hook to remove the ADF plate spring and the Separation rubber ASSY from
the Upper document chute ASSY.
Fig. 3-34
Separation rubber ASSY
ADF plate spring
ADF plate spring
Separation rubber ASSY
Upper document chute ASSY
3c
3b
3a
