1.4.6 Worker Sw WSW) Setting and Printout
[ 1 ] Worker Switch Setting (Function code 10)
<Function>
The machine incorporates the following worker switch functions which may be activated with
the procedures using the control panel buttons. The worker switches have been set at the
factory in conformity to the communications standards and codes of each country. Do not
adjust them unless necessary. Some worker switches may not be applicable in some
versions. The worker switch data list indicates "Not used." for those inapplicable switches.
* Details of Worker switches
The details of the worker switches are described in APPENDIX 1 in which the user-
accessible selectors of the worker switches are shaded.
■ Worker Switches
WSW No. Function Refer to:
WSW01 Dial pulse setting App. 1-3
WSW02 Tone signal setting App. 1-5
WSW03 PABX mode setting App. 1-6
WSW04 TRANSFER facility setting App. 1-8
WSW05 1st dial tone and busy tone detection App. 1-9
WSW06 Redial/Pause button setting and 2nd dial tone detection App. 1-10
WSW07 Dial tone setting 1 App. 1-12
WSW08 Dial tone setting 2 App. 1-13
WSW09 Protocol definition 1 App. 1-14
WSW10 Protocol definition 2 App. 1-15
WSW11 Busy tone setting App. 1-16
WSW12 Signal detection condition setting App. 1-17
WSW13 Modem setting App. 1-18
WSW14 AUTO ANS facility setting App. 1-19
WSW15 REDIAL facility setting App. 1-20
WSW16 Function setting 1 App. 1-21
WSW17 Function setting 2 App. 1-22
WSW18 Function setting 3 App. 1-23
WSW19 Transmission speed setting App. 1-24
WSW20 Overseas communications mode setting App. 1-25
WSW21 TAD setting 1 App. 1-26
WSW22 ECM and call waiting caller ID App. 1-27
WSW23 Communications setting App. 1-28
WSW24 TAD setting 2 App. 1-29
WSW25 TAD setting 3 App. 1-30
WSW26 Function setting 4 App. 1-31
WSW27 Function setting 5 App. 1-32
