<WSW18>
• Selector 1: Header for fax
The setting becomes effective only when do not add the header in the application of the
PC.
• Selectors 2 and 3: Detection enabled time for CNG and no tone
After the line is connected via the external telephone or by picking up the handset of the
machine, the machine can detect a CNG signal or no tone for the time length specified by
these selectors. The setting specified by these selectors becomes effective only when
selector 8 on WSW20 is set to "1."
• Selector 6: Registration of station ID
Setting this selector to "0" permits the registration of station ID for Austrian and Czech
models.
• Selectors 7 and 8: Tone sound monitoring
These selectors set monitoring specifications of the tone sound inputted from the line.
Selector No. Function Setting and Specifications
1 Header for fax 0: With header 1: Without header
2
3
Detection enabled time for CNG
and no tone
No. 2 3
0 0: 40 sec.
0 1: 0 sec. (No detection)
10: 5 sec.
1 1: 80 sec.
4
5
Not used.
6 Registration of station ID 0: Permitted 1: Prohibited
7
8
Tone sound monitoring
No. 7 8
0 0: No monitoring
0 1: No monitoring
1 0: Up to phase B at the calling
station only
11:
All transmission phases both
at the calling and called stations
