3-23
Confidential
8.4 FUSER COVER ASSY
8.4.1
FUSER COVER ASSY
(1) Pull down the Fuser cover ASSY.
(2) Remove the Fuser cover ASSY from the Main body.
Fig. 3-14
Boss
Boss
Fuser cover ASSY
Fuser cover ASSY
2
2
2
1
