3-85
Confidential
8.32 REGISTRATION REAR SENSOR PCB ASSY
(1) Remove the Harness of the Registration rear sensor PCB ASSY from the Guide part of
the Main body.
Fig. 3-88
Harness
Guide part
<Right side>
<Front side>
