8.14 PULL ARM GUIDE
(1) Remove the two Lock claws to remove the two Pull arm guides from the Joint cover.
Fig. 3-55
Joint cover
Pull arm Guide
Pull arm Guide
Lock claw
Lock claw
1a
1a
1b
1b
1b
1b
