8.26 NEW TONER SENSOR HARNESS ASSY
(1) Release the Hook to remove the New toner sensor harness ASSY from the Main body.
Fig. 3-71
CAUTION:
Be careful not to damage the Hook of the New toner sensor harness ASSY.
New toner sensor harness ASSY
New toner sensor harness ASSY
Hook
1b
1a 1a
<Left side>
