3-9
Confidential
6. HARNESS ROUTING
1 ADF motor, ADF sensor PCB ASSY to Main PCB ASSY
Main PCB Shield plate
ADF sensor PCB ASSY
Main PCB ASSY
<Back Side>
ADF motor
