3-80
Confidential
8.30.2
LV SHIELD PLATE 2
(1) Remove the two Taptite bind B M4x12 screws and the two Taptite cup S M3x6 SR
screws, and then remove the LV shield plate 2.
Fig. 3-82
Taptite cup S M3x6 SR
Taptite cup S
M3x6 SR
Taptite bind B M4x12
LV shield plate 2
<Right side>
