10
REFERENCE INFORMATION
SERVICE SPECIFICATIONS
SERVICE SPECIFICATIONS
ENGINE
HP 200 225 250
Full Throttle
Operating Range
4500–5800 RPM
Power
200 HP
(147.1 kw)
@ 5150 RPM
225 HP
(165.5 kw)
@ 5150 RPM
250 HP (183.9 kw)
@ 5150 RPM
Idle RPM in Gear 500 ± 50
Test Propeller
Standard Rotation Models: P/N 436080 or P/N 396277
Counter Rotation Models: P/N 436081 or P/N 398674
Weight
(may vary depending
on model)
20 in. (L) Models: 503 lbs. (228 kg)
25 in. (X) Models: 524 lbs. (238 kg)
30 in. (Z) Models: 530 lbs. (240 kg)
Lubrication
Evinrude/Johnson XD100 Oil
Refer to Recommended Lubricants on p. 164
Engine Type 90° V 6-Cylinder Loop-Charged
Displacement
200.1 cu. in. (3279 cm
3
)
Bore 3.854 in (97.89 mm)
Stroke 2.858 in. (72.60 mm)
Standard Bore
3.8535 to 3.8545 in. (97.87 to 97.90 mm)
To bore oversize, add piston oversize dimension to standard bore
Top Crankshaft Journal 1.6199 to 1.6204 in. (41.15 to 41.16 mm)
Center Crankshaft Journals 2.1870 to 2.1875 in. (55.55 to 55.56 mm)
Bottom Crankshaft Journal 1.5747 to 1.5752 in. (40.0 to 40.01 mm)
Rod Crankpin 1.4995 to 1.5000 in. (38.09 to 38.106 mm)
Piston Ring End Gap, Both 0.022 to 0.028 in. (0.57 to 0.72 mm)
FUEL
Fuel/Oil Ratio EMM Controlled
Starting Enrichment EMM Controlled
Preferred Fuel Regular unleaded gasoline
Acceptable Fuel See Fuel Requirements on p. 134 for additional information.
Minimum (High) Fuel Pressure
@ IDLE RPM – 500 ± 50
22 to 28 psi (152 to 193 kPa)
Minimum Fuel Lift Pump Pressure
@ IDLE RPM – 500 ± 50
3 psi (21 kPa)
Maximum Fuel Inlet Vacuum 4 in. Hg. (13.5 kPa)
Minimum Octane 87 AKI (R+M)/2 or 90 RON
Additives
2+4
®
Fuel Conditioner, Fuel System Cleaner
Use of other additives may result in engine damage.
See Fuel Requirements on p. 134 for additional information.
