210
EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON SYSTEM FAULTS
ICON System Faults
The ICON System exhibits two types of faults: Recoverable and Non-recoverable. ICON System faults
are visually indicated by the remote control, the switch panels, the gateway, and the 6-po rt hub LED’s.
ICON System faults are also displayed on the Faults page of Evinrude Diagnostics and on the NMEA
2000 gauges.
Recoverable Faults
Recoverable faults are Motion or Over-Current errors which occur on a throttle or shift actuator. A motion
error occurs when the ESM is attempting to move an actuator from one position to another, but the actu-
ator does not move. An over-current error occurs when the ESM is moving an actuator and the actuator
draws too much current.
When recoverable fault s are dete cted the remote co ntrol continues to se nd shif t, th rottle, trim, a nd
start/stop commands as normal.
During a recoverable fault, the ICON System:
• Flashes a gear LED of the affected engine one time per second to indicate the gear position command
that caused the fault.
• Sends a fault message to the outboard EMM. The EMM then sends a “Check Engine” message to the
NMEA 2000 gauges.
• Stops shift or throttle actuator movement at the point where the fault occurred
• Will NOT activate S.A.F.E.
When all control levers are put in NEUTRAL, the ICON System
• Stops flashing the FORWARD and NEUTRAL gear LED’s
• Continues to flash the NEUTRAL LED of the faulty engine one time per second
• Allows shift or throttle actuator movement to continue up to the point where the fault occurred
Fault Cause
Binnacle Control
LED’s (flashing)
CSM Remote Con-
trol Switch Panel
LED (flashing)
Control Lever
Position
FWD Shift
Motion or over-cu rrent
error occu rred while mo v-
ing shift actuator fro m NTL
to FWD
FWD NTL
Move control
lever back to
NTL
REV Shift
Motion or over-cu rrent
error occu rred while mo v-
ing shift actuator fro m NTL
to REV
REV NTL
Move control
lever back to
NTL
NTL Shift
Motion or over-cu rrent
error occu rred while mo v-
ing shift actuator from FWD
or REV to NTL
NTL NTL
Move control
lever to original
position (FWD or
REV)
Throttle
Movement
Motion or over-cu rrent
error occu rred while mo v-
ing thro ttle act uator when
in FWD or REV
FWD LED if lever
is in FWD
NTL
Move control
lever toward idle
and beyond the
position where
the fault
occurred
REV LED if lever
is in REV
NTL
