BRP EVINRUDE E-TEC 200 - Fuel System Circuit Diagram

132
FUEL SYSTEM
FUEL SYSTEM CIRCUIT DIAGRAM
FUEL SYSTEM CIRCUIT DIAGRAM
1.
2.
3.
Injectors
EMM
55 V circuit (white/red)
4.
5.
6.
Capacitor
Grounds (neg)
Fuel Injector grounds
7.
8.
High pressure fuel pump
Fuel filter/water separator
007109
