BRP EVINRUDE E-TEC 200 - COMPRESSION TESTING

216
POWERHEAD
SERVICE CHART
SERVICE CHART
17-19 Ft. lbs.
(23-26 N·m)
H
120-144 In. lbs.
(14-16 N·m)
60-84 In. lbs.
(7-9.5 N·m)
B
B
B
38-42 Ft. lbs.
(52-57 N·m)
48-53 Ft. lbs.
(65-72 N·m)
E
H
60-84 In. lbs.
(7-9.5 N·m)
A
F
A
F
120-144 In. lbs.
(13.5-16.5 N·m)
F
60-84 In. lbs.
(7-9.5 N·m)
J
50-70 In. lbs.
(5.6-8 N·m)
B, X
H
E
Install to .92 ± .05
60-84 In. lbs.
(7-9.5 N·m)
60-84 In. lbs.
(7-9.5 N·m)
L
30-42 In. lbs.
(3.5-5 N·m)
L
H
H
84-108 In. lbs.
(9.5-12 N·m)
P, X
Q
B
X
120-144 In. lbs.
(13.5-16.5 N·m)
120-144 In. lbs.
(13.5-16.5 N·m)
144-168 In. lbs.
(16.5-19 N·m)
E
60-84 In. lbs.
(7-9.5 N·m)
F
7-10 In. lbs.
(0.8-1.1 N·m)
Apply Pipe Thread Sealant
to all pipe fitting threads.
A Triple-Guard Grease
B Gasket Sealing Compound
D Moly Lube
E Red Ultra Lock
F Blue Nut Lock
H Outboard Engine Lubricant
J Thermal Grease
L Pipe Thread Sealing Compound
M RTV Sealant
P Permatex #2
Q Gel Seal II
T Liquid Neoprene
X See Service Manual Text
008373
