Remove th e two trim rod rollers from th e swivel
bracket.
Remove the tilt support and bushin g fro m the
swivel bracket and in spect the dete nt roller and
spring.
Stern Bracket Assembly
IMPORTANT: Before proceeding, make sure all
components ha ve be en thoro ughly cleane d.
Replace any seals th at h ave been remove d.
Inspect all thrust washe rs and bushin gs for evi-
dence of deterioration.
Install the detent roller and spring and the tilt sup-
port with bush ing in the swivel bra cket. T ighten
bushing to a torque of 28 to 30 f t. lbs. (38 to 41
N·m).
1. Trim rod roller 30754
1. Tilt support bushing 30753
30752
1. Tilt support bushing 30753
