145
FUEL SYSTEM
FUEL COMPONENT SERVICING
7
Fuel Lift Pump Service
The fuel lif t pump is servicea ble as a co mplete
assembly. Refer to parts catalog for service parts.
Removal
Disconnect the battery cables at the battery.
Disconnect the fue l su pply hose from the in-line
fitting.
Disconnect the fuel outlet hose from tee.
Disconnect the fu el lif t pump pulse hoses at the
crankcase fittings.
Remove clamp scre w, clamp, and oil injection
pump from fuel pump bracket.
Loosen the fue l lif t pump mou nting screws.
Remove the fuel lif t pump and bracket as an
assembly.
Installation
Place fu el pu mp bracket, with rubb er isola tor
mounts, in front of the throttle body.
Apply Nut Lock to screws and inst all screws in to
throttle body. Tighten screws to a torque of 24 to
36 in. lbs. (2.8 to 4.0 N·m).
Connect th e fuel lif t pump pulse ho ses to th e
crankcase. Secure with tie straps.
Connect the f uel outlet ho se to t he fu el filter.
Secure with Oetiker clamp.
Connect the fuel sup ply hose to the in-line fitting.
Secure with Oetiker clamp.
Squeeze primer bulb to prime fuel system. Hold
pressure on bulb and check for fuel leaks.
Install o il injection pump on bra cket with clamp
and screw.
Connect battery cables.
Run outboard and check for fuel leaks.
1. Pulse hose crankcase fitting 005028
004333
1. Screws 004220
