119
ELECTRICAL AND IGNITION
ELECTRIC STARTER SERVICING
6
Starter Assembly
IMPORTANT: If removed, apply Locquic Primer
and Screw Lock to the brush card screws be fore
installing.
Route the brush leads and install the sp rings and
brushes. Compress the spring with a mo dified
putty knife.
IMPORTANT: Incorrect orien tation of the
brushes could damage the st arter or cause
reverse rotation.
Apply Moly Lube to th e armature bushing. Install
the thrust washer and armature.
Align the st arter frame and make sure th e lon g
alignment mark matches the mark next to the pos-
itive terminal stud on the gear housing.
Push the arma ture down firmly and slide the
frame into place. Align the not ches in th e ge ar
housing and frame.
Install insulator cap on end of shaft.
Apply a ligh t coat of Moly Lube to the end ca p
bearing, and install the end cap.
30364
30351
30352
30354B
