178
OILING SYSTEM
OIL COMPONENT SERVICING
OIL COMPONENT
SERVICING
Oil Distribution Hoses
The oil distribu tion hoses from each manifo ld
MUST be the same leng th. DO NOT alter the
length of any hoses.
Removal
Release the hose b y depressing the outer ring of
the hose retaining mechanism.
Once h ose is re moved from the manifold, make
sure hose support is in the end of the hose.
Installation
Cut Repla cement Oil Hose , P/N 778708, to the
correct length. Insert hose support in manifold end
of hose. (Primary manifo ld to rear manifo ld hose
does not use a hose support.)
IMPORTANT: DO NOT insert distribution hoses
into manifold without a hose support.
Be sure the hose is full y in serted into man ifold.
Insertion depth is 5/8 in. (16 mm). Visually inspect
for hose supports.
A WARNING
To preve nt acci dental s tarting while s er-
vicing, discon nect the battery cable s at
the battery.
Oil Distribution Hose Length
Primary oil manifold to
cylinder block fitting
12 in. (305 mm)
Rear oil manifold to
cylinder block fitting
32 in. (812 mm)
Primary oil manifold to
rear oil manifold*
32 in. (812 mm)
*Primary oil manifold to rear oil manifold hose
has a 0.160 in. I.D. and does NOT use a hose
support.
1. Retainer mechanism 004295
1. Hose support 008070
