301
GEARCASE – STANDARD ROTATION
GEARCASE HOUSING INSPECTION
13
Remove propeller shaft assembly from gearcase.
Water Intake Screens
Remove and clean water intake screens. Replace
if damaged.
GEARCASE HOUSING
INSPECTION
Thoroughly clean gearcase housing to remove all
dirt and deb ris p rior to inspe ction. Inspect pinion
bearing an d forward thrust surfa ce of gea rcase
housing.
Use Gearcase Alignment Gauge Kit, P/N 5006349
to check the condition o f gearcase h ousing prior
to reassembly. Refer to instructions p rovided with
kit. Use additional Gauging Head as follows:
• P/N 5007750, for “L2” Type gearcase housings
• P/N 5007749, for “M2” Type gearcase housings
006839
1. Water intake screen 006886
006787
