ELECTRICAL AND IGNITION
REMOTE CONTROL SWITCH TESTS
6
REMOTE CONTROL
SWITCH TESTS
Key Switch Test
Refer to Wiring Diagrams at back of manual.
Use an ohmmeter or a continuity light to test key
switch operation. Replace switch if re sults are
incorrect with any of the following tests.
IMPORTANT: Disconnect ba ttery and ke y
switch wiring before proceeding with the following
tests.
Stop/Ground Terminals (M) – Conn ect meter
between the two “M” terminals. Me ter mu st ind i-
cate NO continuity at START or ON.
Turn key switch OFF. Meter must indicate continu-
ity.
Accessory T erminal (A) – Mak e sure the ke y
switch is OFF. Connect the ohmmeter or continu-
ity light between terminals “B” (battery) an d “A”
(accessory) of key switch. Meter must indicate NO
continuity.
Turn switch ON. Meter must indicate continuity.
Turn key switch to START. Meter must continue to
indicate continuity.
Starter Terminal (S) – Hold key switch at START.
Connect meter between terminal “B” and terminal
“S.” Meter should indicate continuity.
IMPORTANT: The cho ke function or ter minal
“C” of the key switch is NOT used.
Neutral Start Circuit Test
Use an ohmmeter or con tinuity light to test the
continuity of th e circu it while p ositioning th e
remote control in NEUTRAL, FOR WARD, an d
REVERSE.
IMPORTANT: Turn propeller shaft or disconnect
shift cab le to allo w proper re mote cont rol shif t
action while o utboard is not runn ing. Disconnect
the instrument h arness conn ector from the key
switch harness connector.
Make sure the remote contro l han dle is in NEU-
TRAL. Connect mete r between termina l 5
(red/purple wire) a nd terminal 2 (yellow/red wire).
Turn the key switch to START. Meter must indicate
continuity.
Move the remote con trol hand le to FOR WARD
and turn the key swit ch t o ST ART. Meter must
NOT indicate continuity.
Move the remote control handle to REVERSE and
turn the key switch to START. Meter must NOT
indicate continuity.
IMPORTANT: Reconnect shif t cable an d MWS
instrument ha rness co nnector to key switch h ar-
ness connector.
1. OFF
2. ON
3. START
000443
1. Key switch harness connector
2. Neutral start switch
3. Key switch
000443
