352
TRIM AND TILT
TRIM AND TILT SERVICE
Remove the ma nifold. Rem ove f ive O-rings from
cylinder body. Check machined surfaces for nicks
and scratches.
Tilt Piston Removal
Use Tilt Cylinder End Cap Remo ver/Installer,
P/N 326485, or Universa l S panner W rench,
P/N 912084, and a breaker bar to unscrew the tilt
rod end cap.
Drain the fluid from above the piston.
Slowly pull the piston out with a rag wrapped
around the ro d and th e top of the cylinder . Drain
the remaining fluid from the cylinder.
Inspect the bo re of the t ilt cylinder f or excessive
scoring. If the b ore of the tilt cylinde r is score d or
damaged, the hydraulic assemb ly must be
replaced.
Clamp t he rod eye tightly in a soft jaw vise.
Remove the nut from the piston end of the rod.
41799
41788
41789
41765
41767
1. End cap 41781
