EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON SYSTEM FAULTS
211
10
Non-recoverable Faults
When a non-recoverable fault occurs, the ICON System:
• Flashes all gear position LED’s of the affected engine five times per second
• Sends a fault message to the outboard EMM, which in turn se nds a “Check Engin e” message to the
NMEA 2000 gauges
• Activates S.A.F.E.
• Moves throttle actuators to idle, and shift actuators to NEUTRAL, if they are functional
When all control levers are put in NEUTRAL and all engines are in NEUTRAL-idle, the ICON System:
• Stops flashing the FORWARD and NEUTRAL gear LED’s
• Flashes the NEUTRAL LED of the faulty engine five times per second if the condition is ESM or actu-
ator related
• Turns OFF all gear LED’s of the failed remote control lever, if the fault is lever-related
• Disables the faulty control lever or ESM
• Allows unaffected control levers and ESM’s to operate normally
• Retains SYNC function for non affected engines
If a port control lever has failed, starboard lever becomes the lead for SYNC.
If starboard control lever has failed, port lever becomes the lead for SYNC.
Station transfer is not allowed when a non-recoverable fault is present. The ICON System remains in this
state until power is reset
.
Operation stops if the control lever fails on a single binnacle or concealed side mount remote control.
